Yamaha LL-TA TransAcoustic Dreadnought Acoustic Electric Guitar – Brown Sunburst

FEATURES

• Dreadnought body style
• Solid Engelmann spruce top with A.R.E. treatment
• Solid rosewood back and sides
• Designed to provide superb acoustic guitar sound

*Includes Yamaha soft shell case

---

DESCRIPTION

Yamaha LL-TA TransAcoustic guitars transport you to new creative spaces with immersive reverb and lush chorus effects without needing an amp or other external gear.

Perfect for fingerstyle players, the concert body LS-TA has an A.R.E.-treated, solid Engelmann spruce top with rosewood back and sides. It delivers the richness of aged wood while maintaining excellent tone and balance.

Actuator
An actuator installed on the inner surface of the guitar back vibrates in response to the vibrations of the strings. The vibrations of the actuator are then conveyed to the body of the guitar and to the air in and around the guitar body, generating authentic reverb and chorus sounds from inside the body.

Simple Controls
Three simple knobs let you adjust the amount of effects and the line out volume level. Keeping the controls small minimizes the area of the holes in the body material, which reduces acoustic sound loss.
(A) Chorus Control
(B) Reverb Control (Room / Hall)
(C) TA Switch / Line Out Volume Control

* Pressing the TA Switch for longer than 0.3 seconds activates the TA function.
* When a cable is connected to the line out jack, the line out volume can be adjusted by rotating knob (C).
* The reverb type switches from Room to Hall around the 12:00 position.

Designed to Provide Superb Acoustic Guitar Sound
The body is a solid spruce top with mahogany back and sides guitar based on the FG-series.
Louder and stronger sound in the low- to mid-ranges, thanks to cutting-edge acoustic analysis technology developed by the Yamaha R&D Division and a newly-designed scalloped bracing pattern.

Newly-Designed Battery Box
The battery box integrated into the end-pin jack requires fewer holes in the body. This reduces acoustic sound loss. Connect the cable from the jack to a PA or amp to use as an acoustic-electric guitar.

---

SPECIFICATIONS

• Body Shape: Yamaha Original Jumbo shape
• Color: Brown Sunburst
• Finish: Urethane finish with A.R.E. aging process
• Top Wood: Solid Engelmann Spruce
• Back & Sides Wood: Solid Rosewood
• Neck Wood: 5-ply Mahogany/Rosewood
• Radius: 15.75″
• Fingerboard Material: Ebony
• Fingerboard Inlay: Dots
• Number of Frets: 20
• Scale Length: 25.56″
• Tuning Machines: Die-cast gold tuners
• Bridge Material: Ebony
• Nut/Saddle Material: Urea/Urea
• Nut Width: 1.732″
• Electronics: System 70 TransAcoustic preamp with piezo pickup and interior mounted actuator
• Strings: Elixir Nanoweb 80/20 Bronze Light .012 – .053
• Body Length: 20.18″
• Body Width: 16.31″ lower bout
• Body Depth: 4.94″ lower, 3.94″ upper

*Includes Yamaha soft shell case

Model# LL-TA BS
