*USED* DBX 266xs Dynamics Processor

• Error proof operation to smooth uneven levels, add sustain to guitars, fatten drums or tighten up mixes
• New gate timing algorithms ensure the smoothest release characteristics
• Program-adaptive expander/gates
• Great sounding dynamics control for any type of program material
• Separate precision LED displays for gain reduction, compression threshold and gate threshold allow quick, accurate setup
• Stereo or dual-mono operation
• Balanced inputs and outputs on 1/4″ TRS and XLR connectors
• Side Chain insert
• Classic DBX “Auto” mode

Specifications

• Input Connectors – 1/4″ TRS and female XLR (pin 2 hot)
• Input Type – Electronically balanced/unbalanced, RF filtered
• Input Impedance – 40kΩ balanced/unbalanced
• Max Input – >+22dBu Balanced or Unbalanced
• Output Connectors – 1/4″ TRS, male XLR (pin 2 hot)
• Output Type – Impedance-balanced/unbalanced, RF filtered
• Output Impedance – +4dBu: 100Ω balanced, 50Ω unbalanced; -10dBu: 1kΩ balanced, 500Ω unbalanced
• Max Output – >+21dBu balanced/unbalanced into 2kΩ or greater; >+18dBm balanced/unbalanced (into 600Ω)
• Sidechain – 1/4″ TRS Phone, Normalled: Ring = Output (send); tip = Input (return)
• Sidechain Impedance – Tip = >10kΩ (Input), Ring = 2kΩ (Output)
• Sidechain Max Input Level – Tip = >+22dBu (Input)
• Sidechain Max Output Level – Ring = >+20dBu (Output)
• Compressor Threshold Range – -40dBu to +20dBu
• Compressor Threshold Characteristic – Selectable OverEasy® or hard knee
• Compressor Ratio – 1:1 to Infinity:1
• Compressor Attack Time – Scalable Program-Dependent AutoDynamic™
• Compressor Release Time – Scalable Program-Dependent AutoDynamic™
• Expander/Gate Threshold Range – -60dBu to +15dBu
• Expander/Gate Ratio – 1:1 to 4:1
• Expander/Gate Attack Time – <100µs
• Expander/Gate Release Time – Program-dependent
• Bandwidth – 0.35Hz – 90kHz, +0/-3dB
• Frequency Response – Flat: 20Hz-20kHz, +0, -0.5dB
• Noise – <-93dBu unweighted (22kHz measurement bandwidth)
• THD+Noise – Typically <0.2%; Any Amount of Compression @1kHz
• IMD – Typically <0.2% SMPTE
• Dynamic Range – >114 dB, unweighted
• Interchannel Crosstalk – <-95dB, 20Hz to 20kHz
• CMRR – >40dB, typically >55dB at 1kHz
• Stereo Coupling – True RMS Power Summing™
• Power Consumption – 15 Watts Maximum
• Operating Voltage – 100VAC 50/60Hz; 120VAC 60Hz; 230VAC 50/60Hz
• Operating Temperature – 0°C to 45°C (32°F to 113°F)
• Dimensions – 1.75″ x 5.75″ x 19″ (4.45 cm x 14.6 cm x 48.26 cm )
• Unit Weight – 4.84 lbs (2.19 kg)
