SONICAKE Active Signal Mixer, Analog Line Selector, as ABY and FX Loop – Portal

Portal is an active signal mixer with two working modes: parallel and series. In parallel mode, the signal mixer has two send/return loops and one main output, which can combine three independent inputs into one, or can be used as an active ABY as needed. In series mode, A and B are series channels. When the A/B switch is closed, channel A or B is bypassed. When all three switches are closed, it is true bypass. Specifications: Power: DC 9V 5.5×2.1mm center negative, 97mA Dimensions: 124mm (D) x 90mm (W) x 54.8mm (H) Weight: 389g Input Impedance: 1MO Output Impedance: 1kO Send A Impedance:1kO Send B Impedance:1kO Return A Impedance:100kO
