MXR M306 Poly Blue Octave Pedal

Hone Sounds with Contemporary Clarity and Raw Vintage Grit – The MXR Poly Blue Octave Pedal

The MXR Poly Blue Octave brings modern and classic pitch-shifting styles together with fuzz and modulation to create the ultimate octave pedal for tonecrafters and sonic seekers.

The Poly Blue Octave features four separate octave divisions—one octave down, two octaves down, one octave up, and two octaves up—and you get to control the level of each in the mix. Each is polyphonic by default, which means they sound just as amazing with chords as they do with single note passages. Your dry signal gets its own level control, as well, so you can dial in the perfect blend of pitch-shifted tones.
The Mono switch takes you back to the gritty, monophonic tones of analog style pitch shifters. In this mode, the sub-octave signals have the warm vibes and raw personality of a pedal such as the MXR Vintage Bass Octave, while the higher octave signals resemble the Octavio Fuzz with its fuzz intensity dialed all the way back.

Call Up The Thunder and Lightning

The Poly Blue Octave comes equipped with an unruly fuzz that’s inspired by the classic MXR Blue Box™ Fuzz. Applied to all five signals, the fuzz volume can be adjusted using the Dry knob after pressing and holding the Fuzz button. When used with the sub-octave signals, the fuzz sounds thick and subterranean. Over the higher pitched signals, the fuzz is searing and synth-like. Run them all at the same time for a choir of thunder and lightning.

Phase Yourself

For infusing your octave tones with an alluring sense of motion, from thick and syrupy to frenzied and frantic, the Poly Blue Octave features a dual-mode modulation effect. In polyphonic mode, the effect provides an uncanny simulation of the famous Leslie effect, and while in monophonic mode, it provides classic swirls and swooshes inspired by the Phase 90. Like the fuzz effect, the modulation applies to all five signals when engaged. The Mod knob adjusts the rate of the effect—when you want it off, just roll the Mod knob back fully counterclockwise.

Through the EXP jack, the Poly Blue Octave allows you to control various settings with an expression pedal such as the Volume (X)™8 Pedal or an off-board switch such as the MXR Tap Tempo Switch to sweep between two different knob and switch configurations or toggle the fuzz and mono modes on and off.

A Full Palette of Tones and Textures in a Single Pedal

The MXR Poly Blue Octave delivers high-performance pitch shifting, fuzz, and modulation in a ruggedly reliable housing with true bypass switching. Put this into your signal chain, and open up new sonic frontiers.

• EXP jack allows use of expression pedal or tap switch
  to control certain parameters
• FOOTSWITCH toggles effect on/bypass
  (white LED indicates on)
• MOD knob adjusts rate of modulation effect
• DRY knob adjusts output level of dry signal
• FUZZ switch toggles fuzz effect on/off
  (blue LED indicates on)
• SUB-1 knob adjusts output level of signal shifted
  one octave down
• MONO switch toggles between monophonic and
  polyphonic pitch-shifting modes (red LED indicates
  monophonic mode)
• SUB-2 knob adjusts output level of signal shifted
  two octaves down
• OCT+1 knob adjusts output level of signal shifted
  one octave up
• OCT+2 knob adjusts output level of signal shifted
  two octaves up

SPECIFICATIONS

• Input Impedance: 1MΩ
• Output Impedance: 100 Ω
• Maximum Input Level: +5 dBV
• Noise Floor: -97 dBV
• Current Draw: 265 mA
• Power Supply: 9 volts DC

Manufacturer: MXR
Model: M306
SKU: I691804-N-2-WHXD
UPC: 710137126640
