Line 6 HX Stomp Multi-Effects Processor Pedal New

Get big Sound From a Small Unit with The Line 6 HX Stomp Multi-Effects Processor Pedal

HX Stomp is a professional-grade guitar processor that delivers the sound of Helix amps, cabs, and effects in an ultra-compact pedal. Whereas the Line 6 HX Effects pedal is designed to be the centerpiece of a pedalboard, providing full control over individual effects, amp switching, and external MIDI-equipped pedals-HX Stomp is a programmable amp/cab/effects/IR pedal that seamlessly integrates into a variety of environments and applications. Use it as a super stompbox, a backup or travel rig, an add-on tone expander when combined with other modelers, an audio interface-or even a complete guitar or bass rig.

• Utilizes the same DSP chip and HX Modeling as Helix
• Compact yet extremely powerful
• Highest possible audio quality throughout, plus both true bypass and DSP bypass with trails
• Over 300 amps, cabs, and effects from Helix, M-Series, and legacy Line 6 products
• Up to 6 simultaneous amp, cab, and effect blocks (including a looper and IR loading) provide extensive tone-crafting options
• A complete guitar or bass rig in one pedal
• 3 capacitive-sensing footswitches with color-coded LED rings facilitate ease of use and fast editing
• Split/parallel signal paths provide flexible routing for both simple and complex signal chains
• TRS dual expression pedal/footswitch input extends creative control capabilities
• Stereo effects loop (mono/stereo TRS send + stereo returns) facilitates use with other pedals

The same HX Modeling technology that powers the flagship Helix guitar processor enables HX Stomp to run up to six processing blocks simultaneously, with pristine audio quality, making it the most powerful and flexible stompbox-sized guitar processor currently available. There are over 300 amps, cabs, and effects-including a looper. HX Stomp contains all the same HX models found in Helix family products, as well as the legacy effects library from Line 6 M-Series pedals, and stompbox modelers such as the DL4, MM4, FM4, and DM4. There are also presets created specifically for bass players, as well as individual bass amp and cab models.

Additional features include a choice of true bypass and DSP bypass with trails, a stereo effects loop for patching other pedals into the signal chain and 4-Cable Method setups, a jack for connecting two external footswitches or expression pedals, extensive MIDI control, IR (impulse response) loading capabilities, and a multichannel 24-bit/96kHz USB audio interface. The free HX Edit app allows you to customize nearly every aspect of the pedal’s operation, create, save and load presets. It also provides preset librarian capabilities, IR loading, and more.

Intuitive Control and Editing

Despite its tiny size, HX Stomp is easy to both operate and program, thanks to its simple but powerful controls, 320 x 240-pixel color LCD, and three capacitive-sensing footswitches with color-coded LED rings. External control via MIDI and optional expression pedal and footswitch control provide additional flexibility, as does I/O that may be configured for sophisticated routing such as simultaneously feeding an amp and a FOH mixer, 4-Cable Method operation with an amplifier, and easy studio re-amping.

Pristine Audio Quality

An industry-leading 123dB of dynamic range provides tremendous depth and ultra-low noise, while the highest-quality components guarantee unadulterated audio throughout-from inputs to outputs-whether feeding an amp, going direct to FOH, or recording in the studio.

A Complete rig in a Pedal

Whether you need a backup for your Helix or another rig, a travel rig that will fit into a duffle bag with room to spare for cables and additional pedals, a convenient practice and rehearsal rig, or a complete guitar and effects studio recording setup-the HX Stomp provides the perfect solution. It even fits into the top pocket of a Helix Backpack.

SPECIFICATIONS

• Amp models: 93
• Effect models: 266
• Presets: 126 (42 banks x 3 presets)
• Simultaneous Processing Blocks: Up to 8 (DSP permitting)
• Signal Flow Options: Up to 2 stereo, serial or parallel
• Snapshots: 3 per preset
• Impulse response (IRs): 128x 1024 or 2048-point
• Global EQ bands: 3 fully parametric + variable low & high cut
• Main display: 2.4 x 6 inch color display
• Footswitches: 3 capacitive touch with RGB rings + 2x external
• Footswitch modes: Stomp, Preset, Snapshot
• Footswitch types: Latching, Momentary
• Looper types: 1 Switch, Shuffling
• Looper Memory(full speed): 60 seconds mono/ 30 seconds stereo
• Inputs: 1/4 ” Stereo L/R , Return L/R
• Outputs: 1/2″ Main L/R, Stereo Send
• Headphones: 1/4″ stereo
• MIDI: In, Out/Thru + USB
• USB audio interface: 8-in, 6-out w/ re-amping
• Chassis: Cast Aluminum
• Power supply: Line 6 recommends using only the supplied DC-3G power supply

Includes

• Line 6 HX Stomp multi-effects pedal
• HX Stomp Cheat Sheet (read that one first!)
• AC power adapter
• USB cable
• Warranty card

Manufacturer: Line 6
Model: HX STOMP
SKU: I560532-3-WHXX
