Noodles Pedal by Ground Control Audio

The Ground Control Audio Noodles pedal is a revolutionary tone-shaping tool designed for players seeking simplicity and precision. Released in late 2019, it features a digitally controlled, fully solid-state analog signal routing system, ensuring unparalleled reliability and seamless performance on stage or in the studio.

Ground Control Audio Noodles Review

The Noodles pedal combines simplicity with innovation, offering three parallel active EQ channels for bass, mids, and treble bands. Each channel includes three filter settings, resulting in 64 tonal combinations that can be easily adjusted at the touch of a button.

With up to 30dB of gain control per channel, the Noodles provides incredible flexibility for any playing style. Popular among math rock artists like Yvette Young, the pedal lets players enhance their tone without complicated adjustments. Its buffered dry signal ensures that the tone remains pristine while delivering professional-grade audio quality.

Noodles Guitar Pedal Features

• Three active EQ channels for bass, mids, and treble
• 64 tonal combinations with cherry-picked filter settings
• Up to 30dB of gain per channel
• Digitally-controlled, fully analog signal routing
• Buffered bypass with dry signal always active

Noodles Active EQ Specs

• Power requirement: 48mA @ 9VDC
• Input: Center-negative 9VDC (not compatible with 18VDC)
• EQ filters:
  • Bass (40Hz, 100Hz, 280Hz)
  • Mids (400Hz-2.8kHz, 800Hz-2kHz, 1kHz-1.5kHz)
  • Treble (2.8kHz-14kHz, 4kHz-14kHz, 6kHz-14kHz)
• Bypass type: Buffered with solid-state analog routing

What’s in the Box of our Ground Control Audio Noodles Pedal?

• Noodles Pedal
• Branded Pedal Box
• Ground Control Audio Stickers
• Guitar Pick
• Info Card
• DeathCloud Merch
• Candy

*Do not power with anything other than a center-negative 9VDC power supply. This pedal uses circuitry to double up the 9VDC power supply, and you do not want to feed it any more power.
