Fender Limited Edition Suona Jazz Bass Thinline – Violin Burst New

A Fusion of Style and Sound – The Fender Limited Edition Suona Jazz Bass Thinline – Violin Burst

Designed to inspire and captivate, The Suona Jazz Bass® Thinline sings with a refined elegance that echoes the masterful work of a legendary artisan. A stunning adaptation of traditional Fender design, its warm, resonant tones and unmatched beauty are a testament to the dedication and artistry poured into every detail.

• Semi-Hollow Ash Body with Bound Italian Alpine Spruce Top
• Nitrocellulose Lacquer Violin Burst Finish with Matching Painted Headstock
• Custom-Designed Suona Jazz Bass® Pickups
• Roasted Flame Maple Modern “C” Neck
• 7.25″-9.5″ Compound-Radius Ebony Fingerboard
• HiMass™ Vintage 4-Saddle Bridge

Crafted with a semi-hollow ash body and a bound Italian alpine spruce top, this instrument boasts exceptional clarity, lively resonance and a warmth unique to Thinline models. The roasted flame maple modern “C” neck and 7.25″-9.5″ compound-radius ebony fingerboard offer luxurious comfort and limitless playability, while the HiMass™ Vintage bridge adds sustain, resonance and punch. Custom-designed Suona Jazz Bass® pickups produce dynamic and distinct tones with rich harmonics and remarkable depth, while the premium Nitrocellulose Lacquer Violin Burst finish with matching painted headstock complete this timeless instrument.

Experience the perfect blend of tradition and innovation and lose yourself in the luscious tones of the Suona Jazz Bass® Thinline.

SPECIFICATIONS

Body

• Body: Semi-Hollow Ash with Italian Alpine Spruce Top
• Body Finish: Gloss Nitrocellulose Lacquer
• Body Shape: Jazz Bass®
• Body Binding: Single-Ply Black Top Binding
• Body Material: Semi-Hollow Ash with Italian Alpine Spruce Top

Neck

• Headstock: Jazz Bass®
• Neck Matieral: Roasted Flame Maple
• Neck Finish: Satin Nitrocellulose Lacquer with Matched Headcap
• Neck Shape: Modern “C”
• Neck Construction: 4-Bolt Standard
• Fingerboard Radius: 7.25″ to 9.5″ Vintage Compound Radius (184 mm to 241 mm)
• Fingerboard Material: Ebony
• Position Inlays: None
• Side Dots: White
• Scale Length: 34″ (86.36 cm)
• Fret Size: Narrow Tall
• Number of Frets: 20
• Truss Rod: Modern Heel Adjust
• Truss Rod Nut: 3/16″ Hex Adjustment
• String Nut: Bone
• Nut Width: 1.5″ (38.1 mm)
• Nut Material: Bone

Hardware

• Bridge: 4-Saddle HiMass™ Vintage (String-Through-Body or Top-Load)
• Bridge Mounting: 3-Screw Modern
• Pickguard: 3-Ply Black/White/Black
• Pickup Covers: Black
• Control Knobs: Black Plastic
• Hardware Finish: Nickel/Chrome
• Tuning Machines: Pure Vintage Reverse Open-Gear
• String Trees: Vintage-Style Disc
• Neck Plate: 4-Bolt with Custom Suona Logo
• Strap Button: Vintage-Style

Electronics

• Bridge Pickup: Custom-Designed Suona Single-Coil Jazz Bass®
• Middle Pickup: Custom-Designed Suona Single-Coil Jazz Bass®
• Pickup Configuration: SS
• Controls: Volume 1. (Middle Pickup), Volume 2. (Bridge Pickup), Tone
• Switching: None

Miscellaneous

• Saddle Height Wrench: 1/16″ Hex (Allen)
• Truss Rod Wrench: 3/16″ Hex (Allen)

Manufacturer: Fender
Model: 0170291830
SKU: I748417-0-WHXB
