Boss PX-1 Plugout FX Pedal

Explore Legendary Sounds with the Boss PX-1 Plugout FX Effects Pedal

The PX-1 Plugout FX is an innovative hardware platform that captures the timeless Boss compact pedal experience in one versatile pedal. This convertible stomp holds multiple authentic effect recreations from the historic Boss lineup, providing endless fuel for every creative journey. With the PX-1 in your setup, exploring the vast and influential world of Boss compact pedals has never been easier.

• Timeless Boss compact pedals in an innovative hardware platform
• Instantly reconfigure the pedal to use one effect from an onboard library of up to 16 types
• Comes with 16 classic Boss effects: OD-1, SP-1, PH-1, SG-1, CS-1, TW-1, SD-1, DS-1, CE-2, BF-2, PN-2, OC-2, PS-2, VB-2, DD-2, and DF-2
• Additional effects available over time with Model Pass purchases in the Boss Effect Loader app
• Authentic tone and response, realized with powerful DSP dedicated to one effect at a time
• Stereo input and output
• Support for external control with footswitches or an expression pedal
• Tap tempo support and TRS MIDI input for MIDI clock sync
• Bluetooth and USB-C connectivity for loading effect models and more
• Runs on included AC adaptor or USB bus power
• Boss five-year warranty

A Universe of Musical Colors

Since 1977, Boss compact pedals have inspired generations of musicians around the world. Over 140 unique models have been produced, over 19 million units have been sold, and many have remained in non-stop production for decades. From vintage classics and go-to workhorses to rare and specialty effects, the PX-1 puts the diverse Boss compact pedal range at your command.

Authentic Recreations

Backed by newly developed Boss algorithms, each effect in the PX-1 delivers the authentic sound and response of the pedal it’s based on. Every detail is modeled with stunning accuracy, thanks to a powerful DSP engine dedicated to recreating the sound of a single effect at a time. Dial in tones fast with the familiar knob interface you’re used to with Boss compacts, supported by an onboard display for current parameters and internal settings.

Modern Flexibility

The PX-1 supports external control with one or two footswitches or an expression pedal. Use the Swap function to switch between two effects. Or assign nearly any parameter for real-time expressive control while performing. Stereo I/O provides flexible connectivity and enhanced sound for models that support stereo operation, while tap tempo and MIDI clock sync help you get the most out of time-based effects.

An Ever-Expanding Universe

Many more PX-1 effects will be added over time, and each new effect will be available with a low-cost Model Pass within the BOSS Effect Loader app.

SPECIFICATIONS

General

• Sampling Frequency: 48 kHz
• AD Conversion: 24 bits + AF method
• DA Conversion: 32 bits
• Bypass: Buffered bypass

Input

• Nominal Input Level: INPUT A (MONO), INPUT B: -20 dBu
• Maximum Input Level: INPUT A (MONO), INPUT B: +7 dBu
• Input Impedance: INPUT A (MONO), INPUT B: 1 MΩ

Output

• Nominal Output Level: OUTPUT A (MONO), OUTPUT B: -20 dBu
• Maximum Output Level: OUTPUT A (MONO), OUTPUT B: +7 dBu
• Output Impedance: OUTPUT A (MONO), OUTPUT B: 1 kΩ
• Recommended Load Impedance: OUTPUT A (MONO), OUTPUT B: 10 kΩ or greater

Controls and Indicators

• Controls: LEFT knob, CENTER knob, RIGHT knob, Pedal switch
• Indicator: CHECK indicator
• Display: Graphic LCD 128 x 48 dots

Connectors

• INPUT A (MONO) jack, INPUT B jack: 1/4-inch phone type
• OUTPUT A (MONO) jack, OUTPUT B jack: 1/4-inch phone type
• CTL1,2/EXP jack: 1/4-inch TRS phone type
• DC IN jack
• MIDI IN jack: Stereo miniature phone type
• USB COMPUTER port: USB Type-C

Bluetooth

• Profile Support: GATT (MIDI over Bluetooth Low Energy)

Power

• Power Supply: AC adaptor or supplied from the USB port
• Current Draw: 260 mA (AC adaptor), 420 mA (USB)

Accessories

• AC adaptor
• Leaflet (“Using the Unit Safely,” “Important Notes,” and “Information”)
• Roland Cloud Activation Card

Options (Sold Separately)

• Footswitch: FS-5U
• Dual footswitch: FS-6, FS-7
• Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
• TRS/MIDI connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535

Size and Weight

• Width: 73 mm / 2-7/8 inches
• Depth: 125 mm / 4-15/16 inches
• Height: 56 mm / 2-1/4 inches
• Weight (excluding AC adaptor): 400 g / 15 oz

Manufacturer: Boss
Model: PX-1
SKU: I848098-N-14-WHXA
UPC: 761294521571
